| Carrier weight class ¹ | 20 t – 40 t |
| Service weight ² | 2 000 kg |
| Product weight | 1 750 kg |
| Nominal power | 120 kW |
| Rotation speed | 75 rpm |
| Optimum oil flow ³ | 205 l/min – 300 l/min |
| Max. torque @ 350 bar | 23 400 Nm |
| Max. cutting force @ 350 bar | 65 000 N |
| Pick shaft diameter | 30 mm |
| Number of picks | 44 |
| Max. oil flow @ 10 bar | 320 l/min |
| Max. operating pressure | 350 bar |
A: 1,425mm
B: 880mm
C: 720mm
